Pin
|
Function
(Connector A)
|
Pin
|
Function
(Connector B)
|
1
|
Airbag Warning
Lamp
|
1
|
Seat Belt Pretensioner
[Front-Passenger] Low
|
2
|
Ground
|
2
|
Seat Belt Pretensioner
[Front-Passenger] High
|
3
|
(1st stage) Passenger
Airbag Low
|
3
|
Seat Belt Pretensioner
[Front-Driver] High
|
4
|
(1st stage) Passenger
Airbag High
|
4
|
Seat Belt Pretensioner
[Front-Driver] Low
|
5
|
(1st stage) Driver Airbag
High
|
5
|
-
|
6
|
(1st stage) Driver Airbag
Low
|
6
|
-
|
7
|
(2nd stage) Passenger
Airbag Low
|
7
|
-
|
8
|
(2nd stage) Passenger
Airbag High
|
8
|
-
|
9
|
(2nd stage) Driver Airbag
High
|
9
|
Curtain Airbag [Driver]
Low
|
10
|
(2nd stage) Driver Airbag
Low
|
10
|
Curtain Airbag [Driver]
High
|
11
|
-
|
11
|
Curtain Airbag
[Passenger] High
|
12
|
-
|
12
|
Curtain Airbag
[Passenger] Low
|
13
|
Ignition
|
13
|
Side Airbag
[Front-Passenger] Low
|
14
|
K-Line
Diagnostic
|
14
|
Side Airbag
[Front-Passenger] High
|
15
|
-
|
15
|
Side Airbag
[Front-Driver] High
|
16
|
-
|
16
|
Side Airbag
[Front-Driver] Low
|
17
|
Crash
Output
|
17
|
Side Impact Sensor
[Rear-Passenger] Feed
|
18
|
Telltale
Lamp
|
18
|
Side Impact Sensor
[Rear-Passenger] Return
|
19
|
-
|
19
|
Side Impact Sensor
[Rear-Driver] Feed
|
20
|
Front Impact Sensor
[Passenger] Return
|
20
|
Side Impact Sensor
[Rear-Driver] Return
|
21
|
Front Impact Sensor
[Passenger] Feed
|
21
|
-
|
22
|
Front Impact Sensor
[Driver] Return
|
22
|
-
|
23
|
Front Impact Sensor
[Driver] Feed
|
23
|
WCS
|
24
|
-
|
24
|
-
|
|
|
25
|
Side Impact Sensor
[Front-Passenger] Feed
|
|
|
26
|
Side Impact Sensor
[Front-Passenger] Return
|
|
|
27
|
Side Impact Sensor
[Front-Driver] Feed
|
|
|
28
|
Side Impact Sensor
[Front-Driver] Return
|
|
|
29
|
-
|
|
|
30
|
Seat Track Position
Sensor [Driver]
|
|
|
31
|
Passenger Buckle
Sensor
|
|
|
32
|
Driver Buckle
Sensor
|
