1. Rear heater
case (L)
2. Rear heater case
(R)
3. Upper case
4. Upper case
5. Vent
door
6. Expension valve
7. Seal
|
8. Mode
actuator
9. Mode door arm
10. Vent arm
11.
Seal
12. Temp door
13. Blower motor
14. Power
mosfet
15. Temp actuator
|
17. Heater
core cover
18. Heater hose -
inlet
19. Heater hose -
outlet
20. Heater core
21. Refrigerant line
22.
Evaporator core
23.
Insulation
24. Lower case
25. Drain hose
|
