DTC
|
FAULT
DESCRIPTION
|
REMARK
|
B1101
|
Battery
voltage high
|
|
B1102
|
Battery
voltage low
|
|
B1322
|
WCS(Weight
Classification System)ECU Defect
|
|
B1324
|
WCS(Weight
Classification System)Communication Error
|
|
B1325
|
WCS(Weight
Classification System)Wrong ID
|
|
B1328
|
FIS(Front
Impact Sensor)-Driver defect
|
|
B1329
|
FIS(Front
Impact Sensor)-Driver communication error
|
|
B1333
|
FIS(Front
Impact Sensor)-Passenger defect
|
|
B1334
|
FIS(Front
Impact Sensor)-Passenger communication error
|
|
B1346
|
Driver airbag
resistance too High (1st stage)
|
|
B1347
|
Driver airbag
resistance too Low (1st stage)
|
|
B1348
|
Driver airbag
resistance circuit short to Ground (1st stage)
|
|
B1349
|
Driver airbag
resistance circuit short to Battery (1st stage)
|
|
B1352
|
Passenger
airbag resistance too High (1st stage)
|
|
B1353
|
Passenger
airbag resistance too Low (1st stage)
|
|
B1354
|
Passenger
airbag resistance circuit short to Ground (1st stage)
|
|
B1355
|
Passenger
airbag resistance circuit short to Battery (1st stage)
|
|
B1361
|
Pretensioner
front-Driver resistance too High
|
|
B1362
|
Pretensioner
front-Driver resistance too Low
|
|
B1363
|
Pretensioner
front-Driver resistance circuit short to Ground
|
|
B1364
|
Pretensioner
front-Driver resistance circuit short to Battery
|
|
B1367
|
Pretensioner
front-Passenger resistance too High
|
|
B1368
|
Pretensioner
front-Passenger resistance too Low
|
|
B1369
|
Pretensioner
front-Passenger resistance circuit short to Ground
|
|
B1370
|
Pretensioner
front-Passenger resistance circuit short to Battery
|
|
B1371
|
STPS(Seat
Track Position Sensor)-Driver instability
|
|
B1378
|
Side airbag
front-Driver resistance too High
|
|
B1379
|
Side airbag
front-Driver resistance too Low
|
|
B1380
|
Side airbag
front-Driver resistance circuit short to Ground
|
|
B1381
|
Side airbag
front-Driver resistance circuit short to Battery
|
|
B1382
|
Side airbag
front-Passenger resistance too High
|
|
B1383
|
Side airbag
front-Passenger resistance too Low
|
|
B1384
|
Side airbag
front-Passenger resistance circuit short to Ground
|
|
B1385
|
Side airbag
front-Passenger resistance circuit short to Battery
|
|
B1387
|
STPS(Seat
Track Position Sensor)-Driver short or short to Ground
|
|
B1388
|
STPS(Seat
Track Position Sensor)-Driver open or short to Battery
|
|
B1389
|
STPS(Seat
Track Position Sensor)-Driver defect
|
|
B1395
|
Firing loops
interconnection fault
|
|
B1400
|
SIS(Side
Impact Sensor)front-Driver defect
|
|
B1403
|
SIS(Side
Impact Sensor)front-Passenger defect
|
|
B1409
|
SIS(Side
Impact Sensor)front-Driver communication error
|
|
B1410
|
SIS(Side
Impact Sensor)front-Passenger communication error
|
|
B1412
|
SIS(Side
Impact Sensor)rear-Driver communication error
|
|
B1413
|
SIS(Side
Impact Sensor)rear-Passenger communication error
|
|
B1418
|
SIS(Side
Impact Sensor)rear-Driver defect
|
|
B1419
|
SIS(Side
Impact Sensor)rear-Passenger defect
|
|
B1473
|
Inflatable
curtain airbag front-Driver resistance too High
|
|
B1474
|
Inflatable
curtain airbag front-Driver resistance too Low
|
|
B1475
|
Inflatable
curtain airbag front-Driver resistance circuit short to
Ground
|
|
B1476
|
Inflatable
curtain airbag front-Driver resistance circuit short to
Battery
|
|
B1477
|
Inflatable
curtain airbag front-Passenger resistance too High
|
|
B1478
|
Inflatable
curtain airbag front-Passenger resistance too Low
|
|
B1479
|
Inflatable
curtain airbag front-Passenger resistance circuit short to
Ground
|
|
B1480
|
Inflatable
curtain airbag front-Passenger resistance circuit short to
Battery
|
|
B1481
|
Driver airbag
resistance too High(2nd stage)
|
|
B1482
|
Driver airbag
resistance too Low(2nd stage)
|
|
B1483
|
Driver airbag
resistance circuit short to Ground(2nd stage)
|
|
B1484
|
Driver airbag
resistance circuit short to Battery(2nd stage)
|
|
B1485
|
Passenger
airbag resistance too High(2nd stage)
|
|
B1486
|
Passenger
airbag resistance too Low(2nd stage)
|
|
B1487
|
Passenger
airbag resistance circuit short to Ground(2nd stage)
|
|
B1488
|
Passenger
airbag resistance circuit short to Battery(2nd stage)
|
|
B1511
|
Buckle Switch
Driver open or short to Battery
|
|
B1512
|
Buckle Switch
Driver short or short to Ground
|
|
B1513
|
Buckle Switch
Passenger open or short to Battery
|
|
B1514
|
Buckle Switch
Passenger short or short to Ground
|
|
B1515
|
Buckle Switch
Driver defect
|
|
B1516
|
Buckle Switch
Passenger defect
|
|
B1517
|
Buckle Switch
Driver instability
|
|
B1518
|
Buckle Switch
Passenger instability
|
|
B1620
|
Internal fault
- Replace SRSCM
|
|
B1650
|
Crash recorded
in 1st stage only(Frontal - Replace SRSCM)
|
|
B1651
|
Crash recorded
in front-Driver side airbag(Replace SRSCM)
|
|
B1652
|
Crash recorded
in front-Passenger side airbag(Replace SRSCM)
|
|
B1655
|
Crash recorded
(Side - Replace SRSCM)
|
|
B1657
|
Crash recorded
in Belt pretensioner only
|
|
B1658
|
Belt
pretensioner 6 times deployment
|
|
B1670
|
Crash recorded
in full stage(Frontal - Replace SRSCM)
|
|
B2500
|
Warning lamp
Failure
|
|
B2502
|
Passenger
airbag Telltale lamp Failure
|
|
